Truck Mixer Series with SINOTRUK Howo Chassis

Category:

Technical Features

(1)It’s refitted from SINOTRUK Howo class II chassis, featuring excellent power performance, maneuverability, comfort, economy, and operating reliability. (2)The engine features strong power, high energy conservancy and environmental-friendliness, low fuel consumption, and good economy, with the emission pollutants conforming to China-IV emission regulation. (3)The planetary power shift transmission features compact structure, stable gearshift, high efficiency, and long life. (4)Product advantages: The high strength wide-section frame is adopted to effectively reduce the gravity center height of vehicle and the enhanced front and rear shafts and suspensions are adopted to guarantee high driving safety and give full play to the high maneuverability of the vehicle. (5)The large windscreen and large window glasses provide a broad visual field. (6)The instrument panel and instruments of novel design feature smart and beautiful appearances and all control systems of the vehicle are fitted with a warning lamp on the instrument panel. (7)The adjustable steering wheel and the ergonomically designed seat can realize the longitudinal and vertical adjustments and backrest angle adjustment

Performance Parameters

Item
Unit HJC5251GJBD1 HJC5251GJBD2
Mixing drum performance Feeding speed m3/min ≥3
Output speed m3/min ≥2
Output residual rate % <0.5
Concrete slump range mm 50-210
Water supply system Water supply mode Compressor water supply mode
Water tank capacity L 500
Chassis Model SINOTRUK ZZ1257N3847D1
Rated power/speed kW/rpm 249/1900
Maximum traveling speed km/h 78
Minimum turning radius m 19.5 20
Drive mode 6×4
Vehicle specification Full-load gross weight kg 25000
Curb weight kg 13870 14800
Wheelbase mm 3825+1350 4025+1350
Overall dimensions (L×W×H) mm 9340×2496×3850 9870×2500×3975
Hydraulic system Reducer, oil pump, and motor World’s renowned brand
Item
Unit HJC5311GJBD1
Mixing drum performance Feeding speed m3/min ≥3
Output speed m3/min ≥2
Output residual rate % <0.5
Concrete slump range mm 50-210
Water supply system Water supply mode Compressor water supply mode
Water tank capacity L 500
Chassis Model SINOTRUK ZZ1257N3847D1
Rated power/speed kW/rpm 276/1900
Maximum traveling speed km/h 78
Minimum turning radius m 20
Drive mode 8×4
Vehicle specification Full-load gross weight kg 31000
Curb weight kg 16200
Wheelbase mm 1800+3200+1350
Overall dimensions (L×W×H) mm 10360×2500×3940
Hydraulic system Reducer, oil pump, and motor World’s renowned brand
