Feature
Make 12,000 – 14,000 VPM in the vibrato head and remove all excessive water and air
in the raw concrete so that the concrete becomes stronger and better
Make 12,000 – 14,000 VPM in the vibrato head and remove all excessive water and air
in the raw concrete so that the concrete becomes stronger and better
Model | Vibrator dia x length [mm] |
Frequency [vpm] |
Revolution of Flexible shaft [rpm] |
Vibration Amplitude [mm] |
Length of Flexible shaft [mm] |
Weight [kg] |
JCV-32 | 32 x 445 | 12,000~ 14,000 |
3,000~ 3,600 | 1.4 | Standard: 6m (5~8m:available) |
15 |
JCV-38 | 38 x 445 | 1.6 | 16 | |||
JCV-45 | 45 x 445 | 2.0 | 17 | |||
JCV-60 | 60 x 545 | 2.4 | 24 |
